Jenik
J-110/35 M

Underbridge access truck mounted

J-110/35 M : Underbridge Access Truck Mounted J-110/35 M

Some under bridge structures cannot be easily accessed. In these situations, gateway truck J-110/35M can be a wise choice. It is deployed using two towers, and can be inserted in the most confined areas. Its vertical span also allows it to go over major obstacles, such as sound barriers for example.

Specifications

Platform extended length (without tower)
10 670 mm
35’0’’ ft
Retracted length
6 350 mm
20’8’’ ft
Lateral extended length (over sidewalks)
2 390 mm
7’8’’ ft
Vertical extension
4 330 mm
14’2’’ ft
Lower platform width
1 900 mm
6’2’’ ft
Total unit length
10 360 mm
33’9’’ ft
Total width in operation
2 500 mm
8’2’’ ft
Height of the tower
10 360 mm
33’9’’ ft
Platform rotation
180 degrees
Platform maximum weight capacity
550 kg
1 200 lb
Total weight of the unit
23 010 kg
50 728 lb
Erection and extension
On Right
