Jenik
J-200/66 H

Underbridge access truck mounted

J-200/66 H : Underbridge Access Truck Mounted J-200/66 H

Light and highly versatile, it deploys to a considerable 20,3 meters. The main attribute that distinguishes it the most from the others is its lightness. In terms of deployment, J-200/66H weighs approximately 15,000 less than similar models.

Specifications

Platform extended length (without tower)
20 117 mm
66’0’’ ft
Retracted length
13 100 mm
43’0’’ ft
Lateral extended length (over sidewalks)
2 388 mm
7’8’’ ft
Vertical extension
7 315 mm
24’0’’ ft
Lower platform width
1 245 mm
4’1’’ ft
Total unit length
12 192 mm
40’0’’ ft
Total width in operation
2 490 mm
8’2’’ ft
Height of the tower
12 192 mm
40’0’’ ft
Platform rotation
180 degrees
Platform maximum weight capacity
625 kg
1400 lb
Total weight of the unit
27 896 kg
61 500 lb
Erection and extension
Right or left
